THE MXNET 10G ECOSYSTEM

MXNET 10G NETWORK SWITCHES

AC-MXNET-10G-SW24Q

24X 10G SFP+ Stackable Managed Switch
with Two 40G QSFP+

AC-MXNET-10G-SW48Q

48X 10G SFP+ Stackable Managed Switch
with Six 40G QSFP+

AC-MXNET-10G-SW12C

12X 10G Copper (PoE) and Six 10G/25G SFP28

MXNET 10G TRANCEIVERS

AC-MXNET-10G-TCVR

SDVoE 4K HDMI AV-over-IP PoE Transceiver

AC-MXNET-10G-TCVR-AVDM

SDVoE 4K HDMI AV-over-IP PoE Transceiver with Audio Downmixing AVDM Module

AC-MXNET-10G-TCVR-USBX

SDVoE 4K HDMI AV-over-IP PoE Transceiver featuring ICRON’s USB 2.0, ExtremeUSB™ module

AC-MXNET-10G-TCVR-PRO

SDVoE 4K HDMI AV-over-IP PoE Transceiver with a DANTE and ICRON’s USB 2.0, ExtremeUSB™ module

MXNET 10G CONTROL

MXNet Mentor Software

AC-MXNET-10G-CBOX & MXNET MENTOR SOFTWARE
Serving in the role of central commander for an MXNet 10G AV-over-IP system, the AC-MXNET-10G-CBOX maintains communication with all MXNet 10G products, managing multicast data distribution, audio/video switching, and all signal matrixing and routing. AVPro Edge’s state-of-the-art proprietary unmatched MXNet Mentor software platform, features a suite of ecosystem real-time utilities that make system deployment efficient and trouble-free from a single location. Source preview provides convenient video program monitoring

MXNET 10G ACCESSORIES

SMALL FORM FACTOR PLUGGABLE (SFP)

SFP-Plus (SFPP) ports are on every MXNet 10G TCVR and 24 & 48 port network switches, this gives you the option to use Fiber or Copper infrastructure. Additionally, each of these SFP’s comes as a single or a 10-pack.

AC-10G-SFPP-MM: 10G SFP+ 850nm 300m LC Multi Mode Fiber Transceiver Module
AC-10G-SFPP-SM: 10G SFP+ 1310nm 10Km LC Single Mode Fiber Transceiver Module
AC-10G-SFPP-C30: 10G SFP+ Copper RJ-45 Transceiver Module with throughput Up to 30m (98’4″)
AC-10G-SFPP-C80: 10G SFP+ Copper RJ-45 Transceiver Module with throughput Up to 80m (262’5″)
AC-10G-SFPP-C100: 10G SFP+ Copper RJ-45 Transceiver Module with throughput Up to 100m (328′)

SFP 28 (SFP28) ports are on MXNet 12 port network switch. This gives you the option to stack with another 12C network switch, increasing bandwidth for more encoders.

AC-25G-SFP28-MM: 25G SFP28 Multi-Mode Fiber Module
AC-25G-SFP28-SM: 25G SFP28 Single-Mode Fiber Module

Quad SFP-Plus (QSFPP) ports are on MXNet 10G 24 & 48 port network switches. This gives you the option to stack network switches, increasing bandwidth for more encoders.

AC-40G-QSFPP-MM: 40G QSFP+ Multi-Mode Fiber Module
AC-40G-QSFPP-SM: 40G QSFP+ Single-Mode Fiber Module

BREAK OUT CABLES (BOC)

Quad SFP-Plus (QSFPP) ports are on MXNet 10G 24 & 48 port network switches. One 40G QSFPP port can be used as four 10G SFP+ ports by using a break out cable (BOC).

AC-40G-BOC-01: 1m (3’3″) 40G QSFP+ to four 10G SFP+ Break-Out Active Optical Cable
AC-40G-BOC-02: 2m (6’6″) 40G QSFP+ to four10G SFP+ Break-Out Active Optical Cable
AC-40G-BOC-03: 3m (9’8″) 40G QSFP+ to four10G SFP+ Break-Out Active Optical Cable

ACTIVE OPTICAL CABLES (AOC)

Active Optical Cables (AOC) are high speed cables with Small Form Factor Pluggable (SFP) Transceivers on either end. They are used for stacking MXNet network switches or carry data to or from a nearby encoder or CBOX – Let us do the cable terminations

10G Switch to Encoder or CBOX Active Optical Cables

AC-10G-AOC-01: 1m (3’3″) 10G SFP+ Active Optical Cable
AC-10G-AOC-02: 2m (6’6″) 10G SFP+ Active Optical Cable
AC-10G-AOC-03: 3m (9’8″) 10G SFP+ Active Optical Cable

25G Active Optical Cables for stacking a 12C with another 12C

AC-25G-AOC-01: 1m (3’3″) 25G SFP28 Active Optical Cable
AC-25G-AOC-02: 2m (6’6″) 25G SFP28 Active Optical Cable
AC-25G-AOC-03: 3m (9’8″) 25G SFP28 Active Optical Cable

40G Active Optical Cables for stacking a 24 or 48 port switch with another 24 or 48 port switch

AC-40G-AOC-01: 1m (3’3″) 40G QSFP+ Active Optical Cable
AC-40G-AOC-02: 2m (6’6″) 40G QSFP+ Active Optical Cable
AC-40G-AOC-03: 3m (9’8″) 40G QSFP+ Active Optical Cable

MXNET 10G RACK MOUNTING

AC-MXNET-10G-HDRACK

Rack mount for up to twelve 10G Transceivers/Control Box
Mount all Transceivers and a Control Box for a clean looking rack system.

THE POE POWER SUPPLY

AC-MXNET-POE-PSU24

PoE Provider for MXNet End Points
This 24 port unmanaged PoE power supply provides a power only (non-data) CAT cable connection for PoE-enabled IP devices like the MXNet 10G Transceiver.
