Universal Fiber Enclosure
Architecture & Platform Versatility in a Revolutionary FTTH Enclosure for Fiber Demarc and Hardened Fiber Media Converters & Ethernet Switches
PPC’s residential demarcation enclosures are designed to efficiently house fiber optic ONUs as well as all required RF passives for FTTH installs. The unique design separates the optical and RF layers with a hinged partition cover. This improves the installation efficiency with a single housing and prevents errors and downtime created by mishandling.
The internal mounting arrangement allows for a standardized method of installing components. All mounts are the same height and spaced in 1/2” increments per SCTE requirements.
The open-ended, self-sealing cable ports at the bottom of the box allow components to be assembled outside of the enclosure making for quicker installations. The fiber entry port also accepts standard duct couplings for up to 1” conduit.
Note: Internal plates are removable for use with CTC & ROBOfiber Hardened Network Switches & Media Converters
|UV Resistance||30 Days per ASTM G26-93|
|Salt Fog||60 Days per ASTM B117-90|
|Chemical Resistance||30 Days at 100F and 95% RH Resists chipping and/or cracking when subjected to household chemicals|
|Material||Copolymer Impact Polypropylene|
|Dimensions (HxWxD)|| 12”x 11”x 6” – Internal
13″ x 12″ x 7″ – External
|Dimensions||13 × 13 × 7 in|
