Kordz PRO SlimCat Cat6 U/UTP Outdoor Network Cable
NEW! SHIPPING APRIL 2025!
Product Information
Product Documents
Kordz PRO SlimCat Cat6 U/UTP Outdoor Network Cable
Delivering all the power and performance of Cat6 outdoor cable in half the size, the Kordz PRO SlimCat Outdoor Cat6 Network Cable revolutionises outdoor connectivity and goes where other cables can’t. The slim and flexible, yet robust design supports PoE++ for high performance power and data transmission, making it perfect for tight pathways and discrete installations. Ideal for IP cameras, Wi-Fi access points and smart doorbells, it features a black PE UV-stabilised jacket engineered to withstand harsh external conditions and complies with EU, UK and Australian standards. It works seamlessly with existing PRO SlimCat system components and comes backed by Kordz’ 5 Year Warranty.
Product outline
- UV-stabilized PE jacket compliant with EU, UK and AU standards for outdoor use
- Fully compatible with existing PRO SlimCat system components
- Reduced bundle sizes that are half the cross-sectional area of 23/24 AWG network cable bundles
- Performs to industry standards and is fully featured including PoE++ up to 50m
- Conveniently packaged on a 305m drum
- Slim, flexible design enabling discreet installations and dense cable pathways
- Engineered to meet the demands of modern outdoor PoE applications
- Kordz quality with 5 Year Warranty.
Technical info
CONSTRUCTION
Conductor: 28AWG solid OFC 0.338 +0/-0.02mm
Insulation: Polyethylene, 0.61±0.1 mm
Twisting: 4 twisted pairs of conductors
Twisted Pair Colour Code: 1: white-blue / blue 2: white-orange / orange 3: white-green / green 4: white-brown / brown
Shielding: Unshielded (U/UTP)
Cable lay up: Non-Metallic cross separator
Jacket Material: UV resistant Polyethylene-based composite
Outer Diameter: 3.9 ± 0.5 mm
MECHANICAL
Minimum Bend Radius: Without load ≥16.0 mm; with load ≥32.0 mm
Temperature Range: During operation -20 °C to 60°C; During installation 0°C to 50°C
ELECTRICAL
DC Resistance: Max. 23.6 Ω/100 m at 20°C
Resistance Unbalance: Max. 5% at 20°C
Insulation Resistance (500V): Min. 5000 MΩ/km at 20°C
Mutual Capacitance: Max. 5.6 nf/100 m at 1 kHz
Capacitance Unbalance (Pair to ground): Max. 330 pf/100 m at 1 kHz
Nominal Velocity of Propagation: Nom. 67%
Test Voltage (DC, 1min): 1 kV / 1 min
Warranty
The Kordz ONE Cat6 U/UTP Outdoor Network Cable is backed by our 5 Year Product Guarantee
Additional information
| Weight | 32 lbs |
|---|---|
| Dimensions | 14 × 12 × 14 in |
