Kordz ONE Series CAT 6 U/UTP Cable – 305m (1000ft) Pro Box
Product Information
Product Documents
Product outline
Kordz ONE Series CAT6 U/UTP cable is engineered to exceed 4K video installation bandwidth requirements. The Rapid-EZ reel is metre marked and flows from the supplied professional pull box without twisting or curling, minimising snags for optimal installation uptime. ONE series CAT6 cable is tested and approved to exceed 550Mhz, is HDBaseT™ recommended and exceeds ANSI/TIA 568C-2.1 Standard.
- Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX (Gigabit) & 5GBaseT, PoE & PoE+
- U/UTP Ethernet CAT6
- Four Twisted Pairs 24 AWG Oxygen Free Solid Copper Conductors
- Cross Separator Reduces Crosstalk Between Pairs
- Suitable for IDC Terminations
- Supplied in the Durable Rapid-EZ-Reel Packaging – 305m (1,000ft)
- Metre Marked for installation accuracy
- 5 Colours Available: Blue, Green, White, Yellow & Purple
- Exceeds ANSI/TIA 568C-2.1 Standard
- Available In LSZH – IEC60332-1 And UL 444 CM fire rated versions
- CPR Declared Performance: ONE-CAT6: Dca-s2, d2, a1 (EN 50575:2014+A1:2016)
Technical info
CONSTRUCTION
Conductor: Solid OFC annealed bare copper wire 0.537 +0/-0.015mm [24AWG]
Insulation: Polyethylene, 0.97 +/-0.05 mm
Twisting: 4 twisted pairs, 2 cores to each pair
Twisted Pair Colour Code: 1 – white-blue/blue, 2 – white-orange/orange, 3 – white-green/green, 4 – white-brown/brown
Cable Lay-Up: 4 pairs with different pitches, non-metallic cross separator (spine)
Outer Diameter: 5.7 +/-0.3 mm
MECHANICAL
Bend Radius: without load ≥ 22.8mm /0.89”, with load ≥ 45.6mm /1.79”
Temperature Range: During Operation: -20°C to 60ºC During Installation: 0°C to 50ºC
ELECTRICAL
DC Resistance: ≤ 9.38Ω / 100m at 20ºC
Resistance Unbalance: ≤ 5% at 20ºC
Insulation Resistance (500V): ≥ 5000MΩ / km at 20ºC
Mutual Capacitance: ≤ 5.6 nF / 100m at 1kHz
Capacitance Unbalance (Pair to Ground): ≤ 330 pF / 100m at 1kHz
Nominal Velocity of Propagation: nom. 67% c
Test Voltage: 1kV DC / 1 min
MATERIALS/MARKING & FIRE RATING
LSZH
Kordz ONE Solid OFC UHD/4K Video/Data Network Cable. ETL VERIFIED TIA-568-C.2 (3081133CRT-009) LSZH CAT6 U/UTP 24AWG. IEC 60332-1
FRPVC
Kordz ONE Solid OFC UHD/4K Video/Data Network Cable. ETL VERIFIED TIA-568-C.2 (2042398CRT-004) CM CAT6 U/UTP 24AWG. UL 444 CM
Blue: RAL 5015
Green: RAL 6018
Purple: RAL 4005
White: RAL 9003
Yellow: RAL 1018
PACKAGING
Roll Size: 305m / 1000ft – metre marked
Carton Dimensions: 330mm (W) x 265mm (D) x 340mm (H) / 13.0in (W) x 10.4in (D) x 13.4in (H)
Volume: 0.03m2 / 1.05 cu. ft.
Gross Weight: 13.8kg / 30.4lbs
