ROBOfiber HGW-1608SM-PSE – 16x RJ45 + 8x SFP Slot Gigabit Ethernet Managed Industrial Fiber Switches, DIN rail mount, -40 to +75 Celsius

ROBOfiber HGW-1608SM-PSE – 16x RJ45 + 8x SFP Slot Gigabit Ethernet Managed Industrial Fiber Switches, DIN rail mount, -40 to +75 Celsius

Two models available:
With or without PoE+

Unit accepts up to (8) 1GB Single mode or Multi mode SFP Modules
Find them here

Power Supply Kit Required (not included)
Find them here

Availability: In Stock

Product Information

Product Description

The HGW-1608SM-PSE is a 24-port Gigabit Ethernet Managed Switch with 16-port 10/100/1000Base-T(X) and 8-port 100/1000Base-X SFP slot for optical fiber providing stable and reliable transmission for Industrial Ethernet connections. HGW-1604S-PSE is hardened for extreme operating temperatures: -40 to +75 Celsius and has 240W available for PoE PSE power. All ports support 30W PoE+ clients. The managed switch supports a variety of Ethernet functions, including STP/RSTP/MSTP and multiple sub-Ring for redundant cabling, layer 2 Ethernet IGMP, VLAN, QoS, Security, bandwidth control, port mirroring and is housed in IP40 rated rugged metal housings designed to operate in difficult conditions, including mechanically and electrically extreme environments. All Industrial switches have strong surge protection (4kV~8kV) per port, depending on models and strict compliance with IEC and EN standards for industrial grade equipment.

All Industrial Ethernet switches include a DIN rail mounting kit and wall mounting kit.


  • Redundant dual DC input Power 48VDC
  • IP40 rugged metal housing
  • Wide operating temperature -40~75°C
  • Industrial Grade EMS, EMI, EN61000-6-2, EN61000-6-4 Certified
  • 16-Port 10/100/1000Base-T(X) copper ports and 8x 100/1000Base-X SFP slot
  • Reversed power polarity protection
  • STP, RSTP, MSTP for redundant cabling
  • DHCP Server/Client/Relay/Snooping
  • QoS, CoS, bandwidth control for Ingress and Egress, Storm Control
  • Dynamic IEEE 802.3ad LACP Link Aggregation
  • Supports 8kV surge protection on all TP ports
  • Supports IEEE 802.1Q Tag VLAN and port VLAN
  • IGMP snooping V1/V2/V3, IGM P Filtering/ Throttling/ IGMP query
  • Port based and MAC based IEEE802.1X, RADIUS, ACL
  • Software upgrade via TFTP and HTTP
  • Port mirroring, System log, DNS, SNTP, LLDP
  • Web based management, SNMP v1/v2, Telnet
  • 240W total budget of PoE available
  • 802.3af/at (max. 30W) available on each UTP port

Additional information

Weight 2.5 lbs
Dimensions 7 × 6 × 3 in
