Altelix 32x24x12 Fiberglass NEMA 3X Weatherproof Enclosures
The Altelix NFC322412 NEMA 3X Weatherproof Enclosures are ideal for protecting equipment from harsh environments and tampering. Equipment designed for indoor use can now be located outside.
Construction and Features
This rugged IP65 rated enclosure is molded from durable and UV resistant fiberglass reinforced polyester (FRP). The door is fully gasketed making this enclosure suitable for use indoors or outdoors. The lockable door features reinforced hinges and dual quarter-turn latches to secure the enclosure and is locked and unlocked using the included removable keys. A drip rail over the door provides additional protection against water dripping into the cabinet while the enclosure is wet.
This base configuration consists of the fiberglass enclosure with hinged lid. It can be drilled and modified by the installer to suit unique site requirements.
Four mounting feet are included so that the enclosure can be securely mounted to a wall or other structure. Two optional flange and pole mounting kits are available, painted steel (model NMKS-600-08) and stainless steel (model NMKX-600-08).
Optional Lockable Latches
For additional protection of internal equipment installed, three lockable latches are available. The HN-0005 is a keyed lock set which includes two keys. Similar to the HN-0005, the HN-0001 has an interlock feature that traps the key when it is in the unlocked position. The HN-0006 allows the enclosure to be securely locked via use of a padlock (not included). All of these optional lockable latches are direct replacements for the standard quarter-turn latches that come pre-installed in the enclosures.
See Product Documents below for technical specifications.
|Mounting Plate Options|
|Cooling & Heating Options||
No Vents (sealed), Ventilated Enclosure, Vents with Thermostat Controlled Cooling Fan(s), No Vents (sealed) with Thermostat Controlled Heating System, Vents with Thermostat Controlled Heating System, Vents with Thermostat Controlled Cooling Fans and Heating System
